| Size | Number of layers | Loading capacity | Color | Materials |
|---|---|---|---|---|
| L100*D40*H200 | 3 layer 4 layer 5 layer custom |
120Kg/ layer | Blue, white, grey, frosted black, custom | Column: 30*50* 0.5 C steel Beam: 30*50* 0.45 P steel Laminate: 0.3 (0.23 bar) |
| L100*D50*H200 (45 to 55 USD/Set) | ||||
| L120*D40*H200 (47 to 57 USD/Set) | ||||
| L120*D50*H200 (50 to 60 USD/Set) | ||||
| L150*D40*H200 (52 to 62 USD/Set) | ||||
| L150*D50*H200 (55 to 65 USD/Set) | ||||
| L180*D40*H200 (58 to 68 USD/Set) | ||||
| L180*D50*H200 (66 to 76 USD/Set) | ||||
| L100*D40*H200 | 3 layer 4 layer 5 layer custom |
180KG/layer | Blue, white, grey, frosted black, custom | Column: 30*50* 0.7 C steel Beam: 30*50* 0.6 P steel Laminate: 0.4 (0.3 bar) |
| L100*D50*H200 | ||||
| L120*D40*H200 | ||||
| L120*D50*H200 | ||||
| L120*D60*H200 | ||||
| L150*D40*H200 | ||||
| L150*D50*H200 | ||||
| L150*D60*H200 | ||||
| L180*D60*H200 | ||||
| L200*D40*H200 | ||||
| L200*D50*H200 | ||||
| L200*D60*H200 |
| Size | Number of layers | Load capacity | Materials | Color |
|---|---|---|---|---|
| L150*D50*H200 | 3 layer/ 4 layer/ 5 layer |
200Kg/ layer | Column: 40*80* 0.5 C steel Beam: 40*60* 0.45 P steel Laminate: 0.3 (0.3 bar) |
Blue, white, grey, frosted black, custom |
| L150*D60*H200 | ||||
| L200*D50*H200 | ||||
| L200*D60*H200 | ||||
| L120*D50*H200 | 3 layer/ 4 layer/ 5 layer |
240Kg/ layer | Column: 40*80* 0.7 C steel Beam: 40*60* 0.65 P steel Laminate: 0.35 (0.3 bar) |
Blue, white, grey, frosted black, custom |
| L120*D60*H200 | ||||
| L150*D50*H200 | ||||
| L150*D60*H200 | ||||
| L200*D50*H200 | ||||
| L200*D60*H200 |
| The New Light Duty Racking | ||||
|---|---|---|---|---|
| loading capacity(kg) | Shelf thickness | Upright thickness | Beam thickness | |
| 120kg/layer | 0.32mm thick cold rolled steel sheet | 30*50*0.7mm C steel | 30*50*0.6mm P steel | |
| The New Medium Duty Racking | ||||
| 120kg/layer | 0.32mm thick cold rolled steel sheet | 30*50*0.7mm C steel | 30*50*0.6mm P steel | |
| Size（cm） | Body-frame weight（kg） | Sub-frame weight（kg） | loading capacity(kg) | |
|---|---|---|---|---|
| Thicken 200*60*200=4 layers | 44±0.5 | 40±0.5 | 180kg/layer | |
| Thicken 200*50*200=4 layers | 41±0.5 | 37±0.5 | 180kg/layer | |
| Thicken 200*40*200=4 layers | 39±0.5 | 35±0.5 | 180kg/layer | |
| Thicken 180*60*200=4 layers | 41±0.5 | 37±0.5 | 180kg/layer | |
| Thicken 150*60*200=4 layers | 37±0.5 | 32±0.5 | 180kg/layer | |
| Thicken 150*50*200=4 layers | 33±0.5 | 28±0.5 | 180kg/layer | |
| Thicken 150*40*200=4 layers | 30±0.5 | 26±0.5 | 180kg/layer | |
| Thicken 120*60*200=4 layers | 30±0.5 | 26±0.5 | 180kg/layer | |
| Thicken 120*50*200=4 layers | 27±0.5 | 23±0.5 | 180kg/layer | |
| Thicken 120*40*200=4 layers | 25±0.5 | 21±0.5 | 180kg/layer | |
| Thicken 100*50*200=4 layers | 25±0.5 | 21±0.5 | 180kg/layer | |
| Thicken 100*40*200=4 layers | 23±0.5 | 19±0.5 | 180kg/layer | |
| The New 200*50*200=4 layers | 33±0.5 | 29±0.5 | 120kg/layer | |
| The New 150*50*200=4 layers | 27±0.5 | 23±0.5 | 120kg/layer | |
| The New 150*40*200=4 layers | 25±0.5 | 21±0.5 | 120kg/layer | |
| The New 120*50*200=4 layers | 24±0.5 | 20±0.5 | 120kg/layer | |
| The New 120*40*200=4 layers | 21±0.5 | 18±0.5 | 120kg/layer | |
| The New Medium 200*60*200=4 layers | 49±0.5 | 42±0.5 | 240kg/layer | |
| The New Medium 200*50*200=4 layers | 44±0.5 | 38±0.5 | 240kg/layer | |
| The New Medium 150*60*200=4 layers | 41±0.5 | 34±0.5 | 240kg/layer | |
| The New Medium 150*50*200=4 layers | 37±0.5 | 30±0.5 | 240kg/layer | |
