Shibang Steel
1 / 5
| Size | Layers | Loading Capacity | Color | Materials | Price |
|---|---|---|---|---|---|
| L100*D40*H200 L100*D50*H200 L120*D40*H200 L120*D50*H200 L150*D40*H200 L150*D50*H200 L180*D40*H200 L180*D50*H200 |
3 layers 4 layers 5 layers custom |
120Kg / layer | Blue, white, grey, frosted black, custom | Column: 30*50*0.5 C steel Beam: 30*50*0.45 P steel Laminate: 0.3 (0.23 bar) |
45 to 55 USD/Set 47 to 57 USD/Set 50 to 60 USD/Set 52 to 62 USD/Set 55 to 65 USD/Set 58 to 68 USD/Set 66 to 76 USD/Set |
| L100*D40*H200 L100*D50*H200 L120*D40*H200 L120*D50*H200 L120*D60*H200 L150*D40*H200 L150*D50*H200 L150*D60*H200 L180*D60*H200 L200*D40*H200 L200*D50*H200 L200*D60*H200 |
3 layers 4 layers 5 layers custom |
180KG / layer | Blue, white, grey, frosted black, custom | Column: 30*50*0.7 C steel Beam: 30*50*0.6 P steel Laminate: 0.4 (0.3 bar) |
- |
| Size | Layers | Load Capacity | Materials | Color |
|---|---|---|---|---|
| L150*D50*H200 L150*D60*H200 L200*D50*H200 L200*D60*H200 |
3 layers / 4 layers / 5 layers | 200Kg / layer | Column: 40*80*0.5 C steel Beam: 40*60*0.45 P steel Laminate: 0.3 (0.3 bar) |
Blue, white, grey, frosted black, custom |
| L120*D50*H200 L120*D60*H200 L150*D50*H200 L150*D60*H200 L200*D50*H200 L200*D60*H200 |
3 layers / 4 layers / 5 layers | 240Kg / layer | Column: 40*80*0.7 C steel Beam: 40*60*0.65 P steel Laminate: 0.35 (0.3 bar) |
Blue, white, grey, frosted black, custom |
| The New Light Duty Racking | |||
|---|---|---|---|
| Loading capacity | Shelf thickness | Upright thickness | Beam thickness |
| 120kg/layer | 0.32mm thick cold rolled steel sheet | 30*50*0.7mm C steel | 30*50*0.6mm P steel |
| The New Medium Duty Racking | |||
|---|---|---|---|
| Loading capacity | Shelf thickness | Upright thickness | Beam thickness |
| 120kg/layer | 0.32mm thick cold rolled steel sheet | 30*50*0.7mm C steel | 30*50*0.6mm P steel |
| Size (cm) | Body-frame weight (kg) | Sub-frame weight (kg) | Loading capacity |
|---|---|---|---|
| Thicken 200*60*200=4 layers | 44±0.5 | 40±0.5 | 180kg/layer |
| Thicken 200*50*200=4 layers | 41±0.5 | 37±0.5 | 180kg/layer |
| Thicken 200*40*200=4 layers | 39±0.5 | 35±0.5 | 180kg/layer |
| Thicken 180*60*200=4 layers | 41±0.5 | 37±0.5 | 180kg/layer |
| Thicken 150*60*200=4 layers | 37±0.5 | 32±0.5 | 180kg/layer |
| Thicken 150*50*200=4 layers | 33±0.5 | 28±0.5 | 180kg/layer |
| Thicken 150*40*200=4 layers | 30±0.5 | 26±0.5 | 180kg/layer |
| Thicken 120*60*200=4 layers | 30±0.5 | 26±0.5 | 180kg/layer |
| Thicken 120*50*200=4 layers | 27±0.5 | 23±0.5 | 180kg/layer |
| Thicken 120*40*200=4 layers | 25±0.5 | 21±0.5 | 180kg/layer |
| Thicken 100*50*200=4 layers | 25±0.5 | 21±0.5 | 180kg/layer |
| Thicken 100*40*200=4 layers | 23±0.5 | 19±0.5 | 180kg/layer |
| The New 200*50*200=4 layers | 33±0.5 | 29±0.5 | 120kg/layer |
| The New 150*50*200=4 layers | 27±0.5 | 23±0.5 | 120kg/layer |
| The New 150*40*200=4 layers | 25±0.5 | 21±0.5 | 120kg/layer |
| The New 120*50*200=4 layers | 24±0.5 | 20±0.5 | 120kg/layer |
| The New 120*40*200=4 layers | 21±0.5 | 18±0.5 | 120kg/layer |
| The New Medium 200*60*200=4 layers | 49±0.5 | 42±0.5 | 240kg/layer |
| The New Medium 200*50*200=4 layers | 44±0.5 | 38±0.5 | 240kg/layer |
| The New Medium 150*60*200=4 layers | 41±0.5 | 34±0.5 | 240kg/layer |
| The New Medium 150*50*200=4 layers | 37±0.5 | 30±0.5 | 240kg/layer |
