Adjustable Flexible Steel Shelving Long Span Bolted Racks Storage Racks Shelving Units Warehouse Racks

Company Profile

Product packaging

Model & Specifications

Size (cm)	Layers	Load Capacity	Color Options	Materials & Structural Specs	Price Range
L100 * D40 * H200	3 Layers 4 Layers 5 Layers Custom	120Kg / Layer	Blue, White, Grey, Frosted Black, Custom	Column: 30500.5 C steel Beam: 30500.45 P steel Laminate: 0.3 (0.23 bar)	45 to 55 USD/Set
L100 * D50 * H200					47 to 57 USD/Set
L120 * D40 * H200					50 to 60 USD/Set
L120 * D50 * H200					52 to 62 USD/Set
L150 * D40 * H200					55 to 65 USD/Set
L150 * D50 * H200					58 to 68 USD/Set
L180 * D40 * H200					66 to 76 USD/Set
L180 * D50 * H200					-

Size (cm) - Thicker Variant	Layers	Load Capacity	Color Options	Materials & Structural Specs
L100 * D40 * H200	3 Layers 4 Layers 5 Layers Custom	180Kg / Layer	Blue, White, Grey, Frosted Black, Custom	Column: 30500.7 C steel Beam: 30500.6 P steel Laminate: 0.4 (0.3 bar)
L100 * D50 * H200
L120 * D40 * H200
L120 * D50 * H200
L120 * D60 * H200
L150 * D40 * H200
L150 * D50 * H200
L150 * D60 * H200
L180 * D60 * H200
L200 * D40 * H200
L200 * D50 * H200
L200 * D60 * H200

Size (cm)	Layers	Load Capacity	Materials & Structural Specs	Color Options
L150 * D50 * H200	3 / 4 / 5 Layers	200Kg / Layer	Column: 40800.5 C steel Beam: 40600.45 P steel Laminate: 0.3 (0.3 bar)	Blue, White, Grey, Frosted Black, Custom
L150 * D60 * H200
L200 * D50 * H200
L200 * D60 * H200
L120 * D50 * H200	3 / 4 / 5 Layers	240Kg / Layer	Column: 40800.7 C steel Beam: 40600.65 P steel Laminate: 0.35 (0.3 bar)	Blue, White, Grey, Frosted Black, Custom
L120 * D60 * H200
L150 * D50 * H200
L150 * D60 * H200
L200 * D50 * H200
L200 * D60 * H200

Products Description

★ OEM & ODM WELCOME

Product Name: Light Duty Racking
Size: 200*60*200 = 4 layers (or custom)
Suit for: Warehouse Rack, Household, Commercial
Loading Capacity: 120kg-180kg/layer
Upright Thickness: 30*50*0.8mm C steel
Beam Thickness: 30*50*0.8mm P steel
Shelf Thickness: 0.4mm thick cold rolled steel sheet
Feature: Environmental protection spray, Corrosion Protection
Color: Blue, white, gray, matte black

The New Light Duty Racking Specifications
Loading Capacity	Shelf Thickness	Upright Thickness	Beam Thickness
120kg/layer	0.32mm thick cold rolled steel sheet	30500.7mm C steel	30500.6mm P steel

The New Medium Duty Racking Specifications
Loading Capacity	Shelf Thickness	Upright Thickness	Beam Thickness
120kg/layer	0.32mm thick cold rolled steel sheet	30500.7mm C steel	30500.6mm P steel

Size (cm)	Body-frame Weight (kg)	Sub-frame Weight (kg)	Loading Capacity
Thicken 20060200 = 4 layers	44 ± 0.5	40 ± 0.5	180kg/layer
Thicken 20050200 = 4 layers	41 ± 0.5	37 ± 0.5	180kg/layer
Thicken 20040200 = 4 layers	39 ± 0.5	35 ± 0.5	180kg/layer
Thicken 18060200 = 4 layers	41 ± 0.5	37 ± 0.5	180kg/layer
Thicken 15060200 = 4 layers	37 ± 0.5	32 ± 0.5	180kg/layer
Thicken 15050200 = 4 layers	33 ± 0.5	28 ± 0.5	180kg/layer
Thicken 15040200 = 4 layers	30 ± 0.5	26 ± 0.5	180kg/layer
Thicken 12060200 = 4 layers	30 ± 0.5	26 ± 0.5	180kg/layer
Thicken 12050200 = 4 layers	27 ± 0.5	23 ± 0.5	180kg/layer
Thicken 12040200 = 4 layers	25 ± 0.5	21 ± 0.5	180kg/layer
Thicken 10050200 = 4 layers	25 ± 0.5	21 ± 0.5	180kg/layer
Thicken 10040200 = 4 layers	23 ± 0.5	19 ± 0.5	180kg/layer
The New 20050200 = 4 layers	33 ± 0.5	29 ± 0.5	120kg/layer
The New 15050200 = 4 layers	27 ± 0.5	23 ± 0.5	120kg/layer
The New 15040200 = 4 layers	25 ± 0.5	21 ± 0.5	120kg/layer
The New 12050200 = 4 layers	24 ± 0.5	20 ± 0.5	120kg/layer
The New 12040200 = 4 layers	21 ± 0.5	18 ± 0.5	120kg/layer
The New Medium 20060200 = 4 layers	49 ± 0.5	42 ± 0.5	240kg/layer
The New Medium 20050200 = 4 layers	44 ± 0.5	38 ± 0.5	240kg/layer
The New Medium 15060200 = 4 layers	41 ± 0.5	34 ± 0.5	240kg/layer
The New Medium 15050200 = 4 layers	37 ± 0.5	30 ± 0.5	240kg/layer

FAQ

Q What are your trading and payment terms?

1) Payment terms: T/T 30% deposit after order confirmed, 70% balance paid against bill of lading. L/C and O/A options are also available.
2) Lead time: normally in 20-25 days after deposit received.
3) Sample policy: samples are always available for each model. Samples can be ready in 7-15 days once payment is received.
4) Discounts: we offer good discounts for large quantities.

Q How can my goods be delivered?

1) Sea freight: we will update sea freight charges once we know your destination sea port.
2) Agent designated by client: please provide the contact details of your shipping agent and we will arrange to deliver the items.

Q What services do you provide?

1) Your inquiry related to our products or prices will be replied within 12 hours.
2) Well-trained and experienced staff will answer all your inquiries in fluent English.
3) OEM & ODM support: we can help you design customized racking structures.
4) We have highly experienced professional engineers to provide the best solutions.

Q What is the purchase process?

Design drawing → Confirm drawing → Quotation → Proforma Invoice (PI) → Confirm PI → Arrange 30% deposit → Manufacture → QC inspection → Pay balance → Shipping.

Q What are your key advantages and warranty details?

1) Payment: we support O/A 40-60 days.
2) Lead time: fast delivery options are available for rush orders.
3) Price: competitive factory direct sales price.
4) Warranty: Two years warranty. Broken parts will be replaced and sent directly to you.

Q Do you have a Minimum Order Quantity (MOQ) and how are tooling fees charged?

1) MOQ: We do not set a strict MOQ, but larger quantities come with better pricing. We recommend an order quantity that fits at least one 20ft container (approximately 15 tons) for regular products.
2) Tooling Fee: For custom designs requiring new molds, tooling costs are charged before the first order and will be partially or fully refunded once a certain order quantity is met.
