| Size (cm) | Body-frame Weight (kg) | Sub-frame Weight (kg) | Loading Capacity (kg) |
|---|---|---|---|
| Thicken 150*50*200 = 4 layers | 33 ± 0.5 | 28 ± 0.5 | 180kg/layer |
| Thicken 150*60*200 = 4 layers | 37 ± 0.5 | 32 ± 0.5 | 180kg/layer |
| Thicken 200*50*200 = 4 layers | 41 ± 0.5 | 37 ± 0.5 | 180kg/layer |
| Thicken 200*60*200 = 4 layers | 44 ± 0.5 | 40 ± 0.5 | 180kg/layer |
| Medium Duty Racking Details | |||
|---|---|---|---|
| Product name | Medium Duty Racking | Loading capacity | 300kg/layer |
| Material | Cold rolled steel | Shelf thickness | 0.5mm thick cold rolled steel sheet |
| Color | White | Upright thickness | 40*80*1.0mm C steel |
| Beam thickness | 40*60*1.0mm P steel | - | - |
| Size (cm) | Body-frame Weight (kg) | Sub-frame Weight (kg) | Loading Capacity (kg) |
|---|---|---|---|
| Thicken 150*50*200 = 4 layers | 41 ± 0.5 | 35 ± 0.5 | 300kg/layer |
| Thicken 150*60*200 = 4 layers | 45 ± 0.5 | 38 ± 0.5 | 300kg/layer |
| Thicken 200*50*200 = 4 layers | 50 ± 0.5 | 43 ± 0.5 | 300kg/layer |
| Thicken 200*60*200 = 4 layers | 55 ± 0.5 | 48 ± 0.5 | 300kg/layer |
| Item | Value |
|---|---|
| Material | Steel |
| Feature | Corrosion Protection |
| Weight Capacity | 100kg, 200kg/layer |
| Type | Warehouse Rack, light duty rack |
| Length of layers | 120cm, 150cm, 200cm |
| Layer | 5 Layer, 1 Layer, 2 layer, 3 layer, 4 layer |
| Surface Treatment | powder coated |
| Usage | Storage |
| Product name | Light Duty Rack |
| Color | Customized Color |
| Application | Goods Storage |
| Packing | Carton Packing |
| Style | Adjustable Shelf Height |
| Size | Customer Size |
| Function | Large Load Capacity Warehouse Storage |
| Certification | CE/ISO9001 |
| MOQ | 1 Set |
